Revolutionize Your Grinding Process with the CRLM1300 Vertical Grinding Mill!

Production background of CRLM1300 vertical mill CRLM1300 vertical mill is a product of cronus that integrates advanced technologies and design concepts at home and abroad, relying on its deep experience and unique technical advantages in the field of powder equipment. cronus combines local needs and has launched this modern powder processing equipment with high efficiency, […]

Fineness:
80~600 mesh
Capacity:
20~24t/h
Scene:
The equipment is suitable for cement, metallurgy, chemical industry, solid waste treatment, non-metallic, non-ferrous metals, power plant coal grinding and other industries, and is used for grinding cement raw materials, clinker (slag), coal, gypsum, pyrophyllite, calcite, quartz, zinc, tin and other materials.
Vertical mill mainframe

Production background of CRLM1300 vertical mill

CRLM1300 vertical mill is a product of cronus that integrates advanced technologies and design concepts at home and abroad, relying on its deep experience and unique technical advantages in the field of powder equipment. cronus combines local needs and has launched this modern powder processing equipment with high efficiency, energy saving and excellent performance, integrating drying and grinding functions.

As a pioneer in the powder equipment manufacturing industry, cronus is committed to technological innovation. CR vertical mill integrates global advanced technology, continuously optimizes and upgrades, and demonstrates excellent grinding efficiency, stable performance and excellent drying ability. It has won wide recognition in the domestic and foreign markets and has become the preferred brand trusted by customers, demonstrating cronus's unremitting pursuit of technological innovation and quality excellence.

CRLM1300 Vertical Grinding Mill Technical Parameter Comparison Table

Parameter CategoryTechnical SpecificationsComparative Advantages
Grinding Capacity50-300 t/h (adjustable based on material hardness)40%+ higher than ball mills
Feed Particle Size≤80mmDirectly processes medium-crushed materials
Product Fineness80-600 mesh (adjustable)Dynamic separator for precise control
Main Motor Power355-450kW40%-50% lower power consumption vs. ball mills
Grinding Disc Diameter1300mmOptimized grinding area for higher efficiency
Number of Rollers3-4 (hydraulic pressure)Symmetrical layout, uniform pressure
System Pressure8-12MPa (hydraulic adjustable)Adaptable to materials of varying hardness
Floor Space~15㎡ (including auxiliary equipment)50% smaller than ball mill systems
Noise Level≤75dBFully enclosed structure, eco-friendly & low noise

Functional characteristics of CRLM1300 vertical mill

CRLM1300 vertical mill is now used in many industrial fields, including cement manufacturing, metallurgical processing, chemical production, grinding of non-metallic minerals and non-ferrous metal minerals, and coal grinding in power plants.

It is designed for grinding cement raw materials, clinker (including slag), coal, gypsum, and various mineral materials such as pyrophyllite, calcite, quartz, zinc ore, tin ore, etc. Compared with traditional ball mills, CRLM1300 vertical mill has significant advantages: the floor space is reduced by about 50%, the construction cost is reduced by about 70%, and its power consumption is reduced by 40% to 50%. These improvements have greatly enhanced the cost-effectiveness of the product and brought users a more economical and efficient grinding solution.

Vertical Roller Mill Parameter Comparison Table

ModelCRLM1300CRLM1500CRLM1700CRLM2000CRLM2200CRLM2500CRLM2800CRLM3400
Capacity (t/h)20-2425-3438-4865-8090-105110-125125-155190-240
Max. Feed Size (mm)2020253035404045
Raw Material Moisture (%)<10<10<10<10<10<10<10<10
Raw Meal Fineness (R0.08)≤12≤14≤15≤15≤15≤15≤15≤15
Raw Meal Moisture (%)≤1≤1≤1≤1≤1≤1≤1≤1
Main Motor Power (kW)200280400500800100012501800
Unit Weight (t)566888115188220270480

Note: Grindability (Bond Index) ≤12 kWh/t
The above data is for reference only. For detailed specifications, please refer to the product manual or actual equipment.

Hydrated lime production line
sand and powder maker
* The above data is for reference only. For specific information, please refer to the actual product or product manual.
