CRRM serious High pressure Raymond Grinding Mill for Mineral Powder Making Plant

The Handling Materials of High Pressure Raymond Grinding Mill : High-Pressure Raymond Mill Grinding Mill, also called High-Pressure Mill. It is suitable for producing powder in mineral, chemical, building, and other industries.  High Pressure Grinding Mill is suitable for grinding all kinds of materials whose Moh’s hardness is below 9.3, such as calcium carbonate, barite, […]

Fineness:
40-400 mesh adjustable
Capacity:
1-50TPH
Scene:
stone powder plant
raymond mill

High-Pressure Raymond Mill Grinding Mill, also called High-Pressure Mill. It is suitable for producing powder in mineral, chemical, building, and other industries.

High Pressure Grinding Mill is suitable for grinding all kinds of materials whose Moh’s hardness is below 9.3, such as calcium carbonate, barite, dolomite, calcite, limestone, kaolin, bentonite, marble, gypsum, quartz, feldspar, clay, talc, fluorite, clay, white mud, mica, refractory material, glass, total about 1000 kinds of materials.

Internal Structure and Working Principle of High Pressure Grinding Mill:

structure of raymond mill machine

The standard configuration of the High-Pressure Raymond Grinding Mill consists of a main unit, reducer, powder classifier, cyclone powder collector, dust cleaner, blower, control cabinet motor, and pipes. The optional accessories include a crusher, bucket elevator, and feeder.

Big materials are crushed by jaw crusher to the required particle sizes, and carried by bucket elevator to the storage hopper, and are fed evenly and continuously by a vibrating feeder into the main unit for grinding. The grinded powder is carried by the airflow from the blower to the classifier to be classified, the particles which meet the fineness enter the cyclone collector through the pipe and are separated and collected there. They are discharged at the discharging valve to become finished products; The airflow is sucked to the blower by the return pipe on the top of the cyclone collector. The whole airflow system is a sealed circulation and is circulated under positive and negative air pressure.

Benefits of High Pressure Grinding Mill:

  1. Vertical structure, so it has a small footprint and a strong system.
  2. Adjustable particle size:40-400mesh
  3. Compared with other mills, Raymond Mill has a high passing rate - 99%.
  4. The main drive device of Raymond Mill adopts an airtight gear box and belt pulley, the transmission is stable and the operation is reliable.
  5. Important components are made of high-quality castings and profiles, ensuring the durability of the whole equipment.
  6. Centralized control is used in the electric system, the mill can basically realize unmanned operation and the maintenance is convenient.
after-sale team of cronus

Faq of Raymond Mill

what is Raymond Mill used for?

Raymond mill machine used for many kinds of mineral powder processing plants, such as limestone, talc, carbon black, dolomite, gypsum...

What is the discharge size of Raymond Mill?

general the discharge size of Raymond mill is 40-400 mesh.

How do I choose the Suitable equipment for my stone powder production line?

stone grinding mill machine

firstly, we should choose the suitable equipment depending on the fineness we want.
<40 mesh, we should choose a stone crusher, jaw crusher hammer crusher, or European hammer crusher.
40-400 mesh: we should choose the Raymond mill also called the high-pressure grinding mill and pendulum mill.
>400 mesh: we should choose a superfine grinding mill or superfine vertical roller mill.

what is the application of stone powder which is processed by Raymond mill?

Generally, there are many applications of stone powder, such as rubber industry, paint industry, etc., that can also be used as PVC filler and plastic masterbatch.

Why do we use Raymond Mill to process mineral powder? What are its advantages?

Compared with other grinding equipment, Raymond Mill processing mineral powder cost is relatively low, and the equipment service life is long, especially for some small production enterprises, Raymond mill is the most ideal processing equipment. Moreover, the processing fineness range of Raymond Mill covers most of the needs of industrial production for mineral powder fineness, which can well meet the needs of various industries.
Raymond mill products are the most mature equipment, accessories are easy to replace, the price is not expensive.

* The above data is for reference only. For specific information, please refer to the actual product or product manual.
